Pivot Shadowcat Ride GX AXS 27.5" XS

Pivot Shadowcat Ride GX AXS 27.5" XS

$6,999.00 USD
$6,999.00 USD
Sale Sold out
Shipping calculated at checkout.
Size
Color

-pick up in store only-



Lithe, agile, sharp, fast and fun, the Shadowcat is a trail-carving expression of blazing speed and feline creative mayhem. Pivot's latest offering capitalizes on the acceleration and responsiveness of 27.5" wheels and acclaimed dw-link suspension to bring to life a bike that offers transformative capability for riders of every stripe.

Specs from Pivot's Website:

Wheel Size
27.5" (650b)
Frame Material
Carbon Fiber
Frame Material Details
Hollow Core carbon fiber front and rear triangles, size-specific carbon layups; molded down tube, seatstay, and chainstay protection
Rear Travel
140mm
Rear Shock
FOX FLOAT DPS Factory, Kashima coating, trunnion mount, 185mm length x 55mm stroke
Fork
FOX FLOAT 36 Performance, GRIP damper, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Pivot Precision, sealed integrated cartridge bearings
Handlebar
Phoenix Race Low Rise Aluminum, 780mm width
Stem
Phoenix Team Enduro/Trail, 45mm length
Grips
Phoenix Factory, lock-on
Brakes
SRAM DB8, 4-piston, SRAM CenterLine 180mm 6-bolt rotors
Brake Levers
SRAM DB8, tooled reach adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle Transmission, 12-speed, AXS electronic wireless
ISCG Tabs
ISCG05
Chainguide
None
Cranks
SRAM GX Eagle Transmission Alloy DUB, 170mm length
Chainrings
SRAM GX Eagle Transmission, 32 tooth
Bottom Bracket
SRAM DUB, 92mm PressFit
Pedals
None
Chain
SRAM GX Eagle Transmission Flattop, 12-speed
Cassette
SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth
Rims
DT Swiss M1900, 30mm width
Hubs
DT Swiss 370, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with XD driver
Spokes
DT Swiss wheelset
Tires
Maxxis Dissector, 3C MaxxTerra compound, EXO casing, TR, 27.5" x 2.4"
Saddle
XS/SM: WTB High Tail Trail Race Phoenix
Seatpost
XS: SDG Tellis dropper, 105-125mm drop
LG: e*thirteen Vario dropper, 180mm-210mm drop
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
