Pivot Mach 4 SL Pro XO

Pivot Mach 4 SL Pro XO

$8,799.00 USD
$8,799.00 USD
Sale Sold out
Shipping calculated at checkout.
Title
The Mach 4 SL is XC, distilled to its fastest form—engineered for efficiency, sharpened for precision and built to master the modern racecourse. Born from the crucible of World Cup XC and epic endurance racing, it balances a feathery build with an obsession for stiffness, control and efficiency.

Product Details

  • Ultralight Hollow Core Carbon Frame
  • XC-Tuned dw-link™ Suspension
  • XC Adapted Travel-Adjustable Flip-Chip
  • Rear Travel Options from 110 to 120mm
  • RockShox Flight Attendant Options
  • Size-Specific Carbon Layup Across Size Range
  • Low Standover Fits Riders 4’10” to 6’ 7”
  • Full Internal Routing with Pivot Cable Port System
  • 120mm Fork
  • Pivot’s Toolshed™ Downtube Storage
  • Large Water Bottle Clearance on All Sizes
  • Injection Molded Rubberized Frame Protection
  • Pivot Dock Tool System Compatible
Intended Use
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
XS

SM

MD

LG

XL

View Full Geometry
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
High-modulus carbon fiber front and rear triangles; molded chainstay, seatstay, and lower down tube protection
Rear Travel
Setting one: 110mm
Setting two: 120mm
Rear Shock
FOX FLOAT Factory, Kashima coating, 190mm length x 45mm stroke
Fork
FOX FLOAT 34 SL Factory, GRIP SL damper, Kashima coating, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Straight, 52mm
Headset
Pivot Precision, sealed integrated cartridge bearings, IS52 upper/lower
Handlebar
Phoenix Team Flat Carbon, 760mm width
Stem
Phoenix Team XC/Trail, 60mm length
Grips
Phoenix Factory, lock-on
Brakes
SRAM Motive Silver, 4-piston
Rotors: SRAM CenterLine, CENTER LOCK, 180mm front, 160mm rear
Brake Levers
SRAM Motive Silver Stealth, tool-free reach adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless
ISCG Tabs
ISCG05 forward two bolts
Chainguide
None
Cranks
SRAM X0 Eagle Transmission Alloy DUB
Chainrings
SRAM X0 Eagle Transmission, 34 tooth
Bottom Bracket
SRAM DUB, 92mm PressFit
Pedals
None
Chain
SRAM X0 Eagle Transmission Flattop, 12-speed
Cassette
SRAM X0 Eagle Transmission XS-1295, 12-speed, 10-52 tooth
Rims
DT Swiss XR 1700 Alloy, 25mm width
Hubs
DT Swiss, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with XD driver
Spokes
DT Swiss wheelset
Tires
Front: Maxxis Rekon, 3C MaxxTerra compound, EXO casing, TR, 120 TPI, 29" x 2.4"
Rear: Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.4"
Saddle
WTB Volt Pro Phoenix, narrow width
Seatpost
FOX Transfer Factory dropper, Kashima coating
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.4"
Bottle Cage Mounts
One inside front triangle, one under down tube, plus accessory mounts under top tube; compatible with Pivot Dock Tool System
Colors
Blue Stellar Fade, White Avalanche
Warranty
10 years frame, 5 years Pivot/Phoenix components, 1 year paint/finish/bearings
Weight

Miscellaneous
• XC-Tuned dw-link rear suspension design
• Rear travel adjustable via two-position flip chip in linkage/upper shock mount
• Toolshed internal storage in down tube; includes custom made storage bags
• Internal cable routing with Pivot Cable Port System
• SRAM UDH (Universal Derailleur Hanger)
• Frame weights start at 2500 g (5.5 lbs) with FOX FLOAT shock
• Photos may show alternate builds
Price
$8,799.00
